PowerWalker VFI AT 1000 UK
Featuring
USB with Human Interface Device (HID) support
It includes an Intelligent Slot for communication cards
Wide Input Voltage Range for All Environments
It supports AC Generators
Easy to connect Battery Packs
Auto-Dimming LCD (UPS is woken up with Single Button-Click)
It has RPO (Remote Power Off) (Ideal For Roller Shutter Applications)
For more information please contact us on 0330 043 2825 or email sales@upscentre.co.uk
£155.83 Excl. VAT
Description
- USB with Human Interface Device (HID) support
- It includes an Intelligent Slot for communication cards
- Wide Input Voltage Range for All Environments
- It supports AC Generators
- Easy to connect Battery Packs
- Auto-Dimming LCDÂ (UPS is woken up with Single Button-Click)
- It has RPO (Remote Power Off)
The PowerWalker VFI AT is an Online UPS series with double conversion technology, designed to safeguard your mission-critical equipment. Despite its professional application, the VFI AT series is easy to operate and comes inside a compact and economic package.
Multiple optional accessories such as external battery packs and communication cards, enhance the functionality of the UPS and allow for a greater backup time.
Technical Information
| General Features | |
| Type | Online Single Phase (VFI) |
| Phases (IN-OUT) | 1-1 |
| Form Factor | Tower |
| Power Capacity | 1000VA / 900W |
| Output Power Factor | 0.90 |
| Input | |
| Input Voltage Range | 80-300V @ 0-50% load 120-300V @ 50-60% load 140-300V @ 60-80% load 160-300V @ 80-100% load |
| Frequency Range | 40Hz – 70Hz |
| Frequency (Synchronized Range) | Adjustable 1-10% (default ±8%) Outside of the range, it switches to converter mode |
| DC Input (PV) | |
| Input Power Factor | ≥ 0.99 at full load |
| Output | |
| Waveform | Pure Sine Wave |
| VA | 1000 |
| Load Crest Ratio | 3:1 |
| Nominal Output Voltage | 208/220/230/240 VAC |
| THDv | ≤3% @ 100% linear load, ≤5% @ 100% non-linear load |
| Frequency (Battery Mode) | ±0.5Hz |
| Output Power Factor | 0.90 |
| Input & Output Connectors | |
| Input Connector | C14-UK |
| Type G (BS 1363) | 2 |
| Technical Details | |
| LINE Mode Efficiency [%] (Full Load) | 88.0 |
| ECO Mode Efficiency [%] (Full Load) | 95.0 |
| Transfer Time (AC / Line Mode or Battery Mode to ECO Mode) [ms] | 10ms |
| Transfer Time (AC / Line Mode to Battery Mode) [ms] | 0ms |
| Transfer Time (ECO Mode to AC / Line Mode or Battery Mode) [ms] | 10ms |
| Transfer Time (Line Mode or Battery Mode to Bypass Mode) [ms] | 4ms |
| Load Crest Ratio | 3:1 |
| Additional Features | ECO Mode Available, CVCF Mode Available, REPO – Remote Emergent Power-Off, APFC – High Input PF, LCD Display, Battery Pack Available, Circuit Breaker Reset, Generator Compatible, HID – Human Interface Device, AVR – Automatic Voltage Regulator |
| IEC 62040-3 classification | VFI-SS-111 |
| Batteries and Autonomy | |
| Batteries | 2x 12.0V/9.0Ah |
| DC Voltage | 2x 12.0V |
| Recharge Time | 4h to 90% |
| Full Load Backup Time [min] | 3.5 |
| Half Load Backup Time [min] | 11.0 |
| Charger | 1.5A |
| External Battery Pack | GPS40AFP-G3011G5 |
| Recharge Time | 4h to 90% |
| Communication | |
| Communication | USB Type B – for Monitoring Software, RS-232, Management Card Slot |
| Software | PowerMaster |
| Management and Environment | |
| Software | PowerMaster |
| Communication | USB Type B – for Monitoring Software, RS-232, Management Card Slot |
| Noise Level | < 45dB |
| Fan Logic | Always on, Automatic Speed Control |
| Temperature | 0°C – 40°C |
| Humidity | 20% – 90% RH (non-condensing) |
| IP | IP 20 |
| Logistics | |
| Package Height [mm] | 274 |
| Package Width [mm] | 218 |
| Package Depth [mm] | 432 |
| Package Weight [kg] | 10.0 |
| Product Height [mm] | 191 |
| Product Width [mm] | 140 |
| Product Depth [mm] | 327 |
| Product Weight [kg] | 9.1 |
| Package Content | Input Power Cable, Manual, USB Cable, Warranty Card, UPS |
| Manual Languages | EN |
| EAN | 4260074982527 |
| Product Dimensions (DxWxH) [mm] | 327 x 140 x 191 mm |
| Package Dimensions (DxWxH) [mm] | 432 x 218 x 274 mm |
| Pcs. per Outer Carton | 1 |
| Pcs. per Layer | 10 |
| Pcs. per Pallet [Oversized] | 70 |
Manufacture Information
https://powerwalker.com/product/10122186/
Additional Information
- USB with Human Interface Device (HID) support
- It includes an Intelligent Slot for communication cards
- Wide Input Voltage Range for All Environments
- It supports AC Generators
- Several Outlet Versions – Type F, Type E and Type G
- Easy to connect Battery Packs
- Auto-Dimming LCDÂ (UPS is woken up with Single Button-Click)
- It has RPO (Remote Power Off)
The PowerWalker VFI AT is an Online UPS series with double conversion technology, designed to safeguard your mission-critical equipment. Despite its professional application, the VFI AT series is easy to operate and comes inside a compact and economic package.
Rather uniquely among Online UPS, the VFI AT series features outlet sockets for Type F, Type E and Type G plugs. This broadens its usability and allows for different types of application. Multiple optional accessories such as external battery packs and communication cards, enhance the functionality of the UPS and allow for a greater backup time.
